Large spacecraft antennas - New geometric configuration design concepts (1971)

Oliver, R. E · leaf 3

An illustration from Large spacecraft antennas - New geometric configuration design concepts, 1971, leaf 3
Figure 3. Modified Gregorian with hyperbola-generated subreflector ANTENNA AXIS SUBREFLECTOR Figure 4. IWodified Gregorian with ellipse-generated subreflector Multiple-Reffectioo Conical Antenna The basic principle of the multiple-reflection conical antenna concept is illustrated in Figure 5. The…

Interplanetary spacecraft · Liquid rocket propellants · Solid propellant rocket engines · Space simulators · Technologies · Low thrust propulsion · Mission planning · Physiological effects · Spacecraft components · Telemetry · Combustion control · Computer aided design · Interplanetary flight

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
