Diagram of MTKK (Shown in Three Planer) : 1 ~ RDTT Figure 11. of booster stage (diameter of 3.7 m); 2 — external oxygen-hydrogen fuel tank of orbital stage (diameter of 8.4 m); 3 — power unit for attaching RDTT to ex- ternal tank; 4 ~ orbital stage; 5 ~ forward unit for attaching orbital stage to…
Composite materials · Fireproofing · Nonflammable materials · Space suits · Textiles · Equipment specifications · Product development
