Naval architecture: a manual on laying-off iron, steel, and composite vessels (1898)
Watson, Thomas Henry · London; New York: Longmans, Green and co., [etc.] · leaf 327
he butts of the inner bottom are lined off,and the plates ordered from this plan. A little allowance should bemade in the length of the plates for the curve on the bottom fore andaft, or the fore and aft expanded form found. Bevels on Inner Bottom Frames.—Where the double bottomhas fore and aft… … GUN GALLERIES OR SPONSORS. 141 CHAPTER XYI. Obtaining and Fairing Lines of a Midship Gun Gallery—Expansion—Obtainingand Fairing Lines of a Midship Gun Gallery of Conical Type—Expansionof Conical Type—Semi Egg-shaped Forward Gun Embrasure—AnotherForm of End Gun Gallery—Expansion of End Gallery. GUN…
Naval architecture -- Handbooks, manuals, etc · Naval architecture · Ships, Iron and steel
