to C A until theymeet their correspondinginclined lines ■ then theheights lifted and set offabove the depth mouldedline will give a perfectlyfair line. Where the LowestPoint is not on the Mid =ship Frame or midwaybetween the Perpendi =culars. — This, in someyards, is the case, then thelength… … *gp lib/^ OF THK UNIVERSITY LAYING-OFF THE SHEER DRAUGHT. 23 3, etc., as shown, then theline K 0 B will be the sheercontracted in the length.It can be lifted on to theSheer in Fig. 14 above thedepth moulded, by takingthe distance above C A toeach of the points. It will be readily seenthat any…
