*-^s ,^ to 16 The Geometrical Development mica lanterns, shown in Fig; 4; also oil bottles, Fig. 15;colanders, Fig. 17; wash dishes, Fig. 18. To obtain thispattern we proceed thus: If it is required to make acolander, Fig. 17, 12 inches at the brim a b, then the 12 X Krule is =9, and four-sixths of…
