Notes and examples in mechanics; with an appendix on the graphical statics of mechanism; (1897)
Church, Irving P. (Irving Porter), 1851-1931 · New York, J. Wiley & Sons · leaf 130
ormly acceler-ated motion. Its time-velocity curve is a straight line, BH^Fig. 130, the initial velocity %\ being rep-resented by OB^ and the final, y^ (fort ^ ^„), by HN. The distance described isrepresented by the area of the trapezoidOBHN. This area is equal to that of arectangle of the same… … H A ^^y^ L ^^ B ^n 0 N —^«— Fig. 130. 122 NOTES AND EXAMPLES IN MECHANICS. If the initial velocity of the uniformly accelerated motion igzero, the time-velocity curve becomes a straight line passing/ through the origin, O^ viz., 011^ Fig. 131;/ and in that case the distance ,9^ is repre-sented by…
