rigid body A . , B,hanging at rest, must have a direction verti-cally upward, and an amount, F, numericallyequal to G, while its action-line, c , . d, passesvertically through the centre of the hinge-circle.In Fig. 18 is another two-force piece, inwhich, for equilibrium, the same result isreached,… … Fig. 18. THEEE-rORCE PIECES. 19 Bell Crank.
