Wallis, Rolland S. [from old catalog], Iowa state college of agriculture and mechanic arts, Ames. Dept. of engineering extension. [from old catalog] · Ames, Iowa, Engineering extension department, Iowa state college · leaf 8
Fig. 4.-Relative positions of drawing board, T-SQuare and triangles. drawn along the triangles only in the directions indicated by the ar-row™ that is, always away from the body and to the right. The lineswhich may be drawn with the 30°-60° triangle are shown combined mFig. 5j and those with the… … (h) (i) <j> ^^W- Fig 5.—The triangles used separately. Lines parallel to any given line may be drawn conveniently by bring-ing one edge of a triangle to coincide with the line, and then placing
Mechanical drawing
