nt P, Fig. 188, which indicates the condition of the gas as the cylinder was placed on the insulating stand, now moves along the adiabatic line PQ. The adi- abatic compression is now continued until the temper-ature of the gas rises to the temperature T of the hot body. In producing this… … b Fig. ISS. a c d Carnots cycle. 326 THERMODYNAMICS. Operation 2. Tlie cylinder is then removed from tlie insulat-ing stand and placed upon the hot body and the piston allowedto rise. The gas then expands, and an amount of heat equal toH at the temperature T flows into the gas through the…
