irst, then pro-jecting dow^n from the plan. Put the dimensions on practi-cally where shown on the sketch. When ready to ink, put in the small arcs with the bowpen, then the larger with the compass, and lastly the straightlines. Put in the dimension lines and figures the very last. 18. Detailed… … N ^^ Curves and Straight Lines Combined, and Sections 33 making them carefully full size, using the scale for layingout the sizes. Draw the horizontal and oblique center lines of bothviews first. Next draw the central boss and left hand endof the lower view or elevation. Then draw the fork of the…
