Notes on X-light (1903)

Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 440

An illustration from Notes on X-light, 1903, leaf 440 — CC Figure 3 M H Figure 1 NOTE i—FIGURE i — COOLED TARGETX-LIGHT TUBE Plate 3 /n\ * … SOFTRUBBERTUBE, t OUTLET. INLET. NOTE 4 —FIGURE 4 —COOLED TARGET TUBE,WITH MOVABLE CATHODE Plate 4

X-rays · Phototherapy
