Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 444
NOTES 15 AND 16 — FIGURE 1 — X-LIGHT TUBE,WITH ANNULAR ANODE, TO SHOW THATTHE POSITION OF THE ANODE DETER-MINES THE POINT FROM WHICH X-LIGHTWILL ARISE Plate s … NOTES 16 AND 17 —FIGURE 2 —X-LIGHT TUBEIN WHICH THE TARGET IS PLACED BE-TWEEN THE ANODE AND THE CATHODE.THE TARGET CAN BE MADE AN ANODE,WHEN DESIRED, BY CONNECTING IT BY AWIRE WITH THE ANODE Plate 6
X-rays · Phototherapy
