Notes on X-light (1903)

Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 510

An illustration from Notes on X-light, 1903, leaf 510 — NOTE 65 —FIGURE 61 —COOLED TARGETDOUBLE FOCUS X-LIGHT TUBE Plate 30 … Vd NOTE 65 —FIGURE 60 —DIAGRAM SHOWING . THE PLAN ON WHICH THE TUBE SHOWN IN FIGURE 58, PLATE 28, IS CONSTRUCTED Plate 31

X-rays · Phototherapy

Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
