Notes on X-light (1903)

Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 570

An illustration from Notes on X-light, 1903, leaf 570 — 3 M \ \ u- \ a\ » O 1 ( 1 / / I Ul / / co / £ 1—o*^ / ° —* / i 3 NOTE 137 —FIGURE 3^-A SECTION THROUGHTHE SECONDARY OF AN INDUCTION COILHAVING INTERCHANGEABLE SECONDARYSECTIONS SHOWING GLASS TRAYS. A,GLASS PLATE SEPARATING THE COILS OFONE SECTION; B, COIL; C, MICANITE TUBE Plate 61 Ev.G

X-rays · Phototherapy

Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
