Notes on X-light (1903)

Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 656

An illustration from Notes on X-light, 1903, leaf 656 — Figure 4 NOTE 149 —FIGURE 5 —A PERSPECTIVE VIEWOF A NON-RADIABLE TUBE BOX Plate 102 A … XX X X NOTE 149 —FIGURE 5 A —A TUBE BOX WITHAN ADJUSTABLE, CENTRING DIAPHRAGM;SHUTTER; ORIENTER; VACUUM REGULA-TOR AND ADJUSTING RODS Plate 103

X-rays · Phototherapy
