Fig. 60. — Ground-plan of the Nieuwe-Kerk at Amsterdam.(Scale, .039 inch to the 3ard.) these treasures have since disappeared. The walls are bare,poor, and somite in appearance. Ficr. 59 shows the general arranirement of the timber roofcovering the principal nave. This vault is composed of… … Fig. 61. — Section of Aisle.(Scale, about ^ g ich to the yard.) 106 HOLLAND. have been given to them if they had been constructed of stone.These arches are connected by cross-beams which render themrigid, and on which rest the phmks forming the vault; thediagonal and wall ribs rest on a small…
