Notes and sketches of an architect taken during a journey in the northwest of Europe; (1877)
Narjoux, Felix, 1836-1891 · Boston : J. R. Osgood · leaf 113
Fig. 63.—View of the Wester-Kerk at Amsterdam. more compact and correct, if we may use the expression; arather narrow aisle surrounds the nave. Several chapels erected 108 HOLLAND. on the right side of the transej)t must, by their arrangements,have greatly contributed to the splendor of Koman… … Fig. 64. • Ground-plan of the Church of the Sacred Heart at Amsterdam. (Scale, .078 inch to the yard.) roof cannot be earlier than the seventeenth century; it is con-structed in the same manner as those which we have alreadydescribed, but the plan is not so good, and it is not so well exe-cuted or…
Architecture
