■ £ 10- Ts io «MS Fig. 146. — Qrotind-plan of Roman Catholic Chxirch at Hamburg. the roofs of the side aisles. Arches placed below these roofs,the timber-work of which is supported by them, sustain thethrust of the vaults of the nave. HAMBURG. 277 The steeple is over the main entrance, and forms… … 2V 7 0MAii/<IEtyJCX Fig. 147. — View of the Interior. the purpose for which it is intended. First, the porch; then,the window belonging to the organ gallery; and above this, thelong: narrow windows of the belfry, over which is the base of thewooden spire. Triple windows, resembling those of the…
