83 SAIL PLAN OF POLE MAST SLOOP. Mainsail. 9—Fore staysail tack. peak. 10— clew. throat. 3—Jib. tack. 11— head. clew. 12— tack. Fore staysail. 13— clew. head. SAIL PLAN OF TOPSAIL SLOOP. 35 SAIL PLAN OF TOPSAIL SLOOP. 1— Mainsail. 6— peak. 7— throat. 8— tack. 9— clew. 2— Fore staysail. 10— head.… … \ 87 SPAR AND RIGGING PLAN OF YAWL. 1— Hull. 2— Cabin house. 3— Cockpit rail or coam- ing. 4— Main mast. 5— Mizzen mast. 6— Main boom. 7— gaff- 8— Mizzen boom. 9— gaff- 10— Main sheet. 11— Mizzen 12— Main peak halyards. 13— Main throat halyards. 14— Mizzen peak 15— throat 16— Main topping lift. 17—…Yachts · Yachting
