Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .. (1905)

Hand, L. H. (Louis Henry), b. 1854 · Chicago, F. J. Drake & co. · leaf 123

An illustration from Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .., 1905, leaf 123
of work that an ordi-nary moulder couldnot put it togetherand get a mouldfrom it; in conse-quence it had alwaysto be taken to thefoundry by the pat-tern maker. Thefoundry made alabor charge of $5.00on this work, inaddition to the weightof the brass, for eachand every whistlecast. Having de-cided… … AND FOUNDRY PRACTICE 119

Patternmaking · Founding
