Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .. (1905)
Hand, L. H. (Louis Henry), b. 1854 · Chicago, F. J. Drake & co. · leaf 56
rtions of the work. Fig. 18 represents a paring tool, of which notmore than two sizes are usually needed. Thistool is used to finish the work in the lathe afterit has been roughly formed by the gouge. Theflat chisel. Fig. 19, is used for turning beads,ovals, etc., and for sizing particular work as… … itili itoseci cAist? The parting tool, Fig. 20, is used for cuttingdeep grooves and for cutting off work in thelathe. The diamond point. Fig. 21, and the 52 PATTERN MAKING bull-nosed chisel. Fig. 22, are used for turningboth the outside and inside surfaces of hollowpatterns, such as the piece shown…
Patternmaking · Founding
