.4 of aninch at a right angle from the pitch line a-a^and a-f at the pitch diameter, the profile of a coneis obtained to which the teeth or cogs may be *The exact decimal is 21.9912. AND FOUNDRY PRACTICE 89 glued with accuracy and precision. The calcula-tion for both ends of the teeth should be… … centers so established and finish in the usualmanner. Fig. 49, showing an iron dome with projectingornament at the top and a handle at each side, ishere introduced as a sample of what may bedone with hollow cores. Assume that a roughform has been glued up as shown in cross-sectionin Fig. 50. Attach…
