Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 139

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 139
Fig. 211. Method of Turning.Up Elbows 122 PATTERN MAKING whole is then glued and screwed to the board c, and the two triangu-lar blocks d and d are glued in the angles to add strength to thecompleted box. In case the pattern is for a very small pipe, \\inches or under, the part b may be abutted… … Fig. 212. Turued-Up Flanges and Core Prints shown by the dotted line, and the side of a at e cut away to the samecurve as 6, giving the same results as in the former method. Pipe Elbow. The pattern for the 2-inch elbow, Fig. 209, isanother illustration of how such work may be simplified, and…
