=fl)==<ll> … Fig. 259. Template Used to Lay Out Teeth of Spur Gear the bar on which the template revolves. This notch is shown inFig. 259. To use the template, place it over the center pin and bring thenotch exactly in line with one of the spacing lines on the outsideof a block, and with a very sharp pointed…
