Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 167
es will be needed for a great number of wheels. Fastening, When the teeth arelarge, they must be screwed on fromthe inside of the rim. If small, theyshould be bradded from the outsideor face of the tooth into the rim afterthe teeth have been shaped andfinished. Templates. Two templates willbe… … Fig. 265. Construction of Template
