Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 177
illustrate the appearance of theseflanges, the pieces j and k being sawed to the full length and thetenons produced with the machine saw. The grain of the stockshould be as nearly parallel to the length of each piece as possible.The layout for these flanges need only be made on one pieceof stock.… … one at each end—not near each other at the center, and not in thewaste stock. These same nails will then hold the pieces firmlytogether while the edges are being trimmed smooth and true. Shouldthe depth h be over 12 inches, an intermediate flange should be madeand placed between the openings m and…
