Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 178

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 178
an the requiredwidth, being filed out in thecasting. A pattern for the drawpieces I and I is to be made as shown in Figs. 274, 277, and 278;the radii c and d being shown in Fig. 272. The thickness is u, andan enlargement at one end is provided to serve as a handle. Twocastings from this pattern are… … Fig. 27S. Draw Piece3 for Core Box 160 PATTERN MAKING H IS ion Of

Patternmaking
