Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 49

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 49
Fig. 73. Typical Pattern Makers Hammer in pine and other soft woods. It is true that the mallet head willnot last so long if made of beech or maple wood, but the chisel and gouge handles will beprotected, which is amatter of much greaterimportance. Screwdriver and Aids.Of the screwdriver,… … Fig. 74; Mallet

Patternmaking
