Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 58
1 Fig. 89. Medium-Sized Faceplate Construction PATTERN MAKING 43 the rest so as to use only the extreme point of the tool, but should betilted over, first to one side and then to the other, so as to bring all … a b Fig. 90. Strongly Braced Faceplate for Large Work parts of the cutting edge, successively, in contact with the wood thatis being turned. The gouge may be used by the beginner without hesitation,as in no position, whether tilted or on its back, will it catch or ripinto the wood. The tool should…
Patternmaking
