Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 103
nd the block for the hub isglued over the center. Six segments to formthe outer rim are glued around on the outeredge, care being taken to break joints, asshown in Fig. 162. If the groove is to belarge, the six segments should be of half thethickness only, and a second set of segments of like… … Fig, 161. Segmental Con. struction of Web for Sheave Pattern
Patternmaking
