Fig. 171. Construction of Arm Pattern thus obtained to the center. These radii will be the central lines ofthe arms, as shown by the dotted lines in Fig. 171. On each side of the intersection of the radii and outer circle,measure | inch to the right and left, and on the circle denoting…
