Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 130

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 130
e, and the same on theend of the hub; yq inch will be sufficient to add for finish on theouter rim, making the diameter of the pattern 16f inches, and thethickness of the disk f inch. A sectional view of the pattern isshown in Fig. 195. Disk, The disk or web for this pattern is to be made of… … Fig. 104. Disk Crank 114 PATTERN MAKING glue sized, and be grooved for a spline. The grain of the stock usedin these splines should be at right angles to the joint, as mentionedin the consideration of the hand-wheel pattern, Fig. 171. Bandsaw this web to a diameter J inch greater than required for…
