Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 205
illustrate the position of the draw plate and levers when thepattern has been drawn. Stripping Plate. A perspective sketch of the stripping plateis illustrated in Fig. 314, part of the casting having been brokenaway to illustrate the position of the holes through which the patternis drawn, and Fig.… … in tAe ncntei moid. Fig. 314. Diagram of Stripping Plate. One Bod Brokea to Show Holes throughWhich Pattern Is Drawn — Cope core print. The pattern pa.ris onthis line
