Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 208
Fig. 320. Casting forPattern c, Fig. 312 Fig. 321. Master Pattern for Part c with the levers and links. Fig. 325, do not require a pattern, butaccurate sketches or drawings, preferably full size, should be madeby the pattern maker for these parts for the use of the metal-pattern maker. Owing to the…
Patternmaking
