Fig. 322. Core Box for Master Pattern,Fig. 321 Fig. 323. Sketch of Stool e, Fig. 312 this side of the casting on a match plate, Fig. 326, and, while apneumatic vibrator is shown, possibly it may not be necessary. The vibrator is operatedwhile the plate is beingdrawn or lifted from thecope mold,…
