equal length, and letC be on L.D., it is plain if lines parallel to AB and of equallength be drawn on G.P. within the P.P., they will appearshorter than AB. Find points M, IS and join BM, CM, etc.Then AF = AB, GB = BC = AB, etc. Hence FG = AB, GH =BC, etc., also AF = BG, BG = CH, etc., and the… … 30 DRAWING. To represent a square perpendicular to G.P. and P.P. Let H.L. and B.L. be drawn, also L.D., and tind X. Take
