Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 79
Fig. 44. 76 DRAWING. Example 2.—Draw a cylinder lying on G.P., 4 to right,having end perpendicular to P.P., and touching it; cylinder8 long and 3 in diameter. … Take A, 4 to right and E, 4 to left; make AB = 1J, anddescribe circle; join B C.V. and A C.V., also E MP, and fromC, draw CD parallel to AB, and describe smaller circle: thendraw common tangents, completing the cylinder (Pig- 45.) THE CYLINDER. 77 Example S.—The figure shows how to draw a common…
Geometrical drawing · Perspective
