Photographs and descriptions of various kinds of engines [ca. 1916] (1916)
United States · leaf 46
Five Fece Radial Drill. Pe The arm or jib has a radius oe five feet ae the center of the column to hel scenter of the drill spindle. Base has large vertical and horizontal faces, with slots for bolting work. Drill spindle 24 inches diameter, 16 inches averse with hand and power feed. ‘Distance from…
Engines · Pictorial works · Engines -- Pictorial works
Internet Archive · Smithsonian Libraries and Archives · Public domain (published before 1931). Free to use for anything.
![An illustration from Photographs and descriptions of various kinds of engines [ca. 1916], 1916, leaf 46](https://img.insideoutlibrary.com/img/1024/ia-photographsdesc00unit-46-0.webp)
