Plastering, plain and decorative. A practical treatise on the art & craft of plastering and modelling, including full descriptions of the various tools, materials, processes, and appliances employed ... together with an account of historical plastering in England, Scotland, and Ireland, accompanied by numerous examples (1899)
Millar, William, d. 1904, Robinson, G. T · London : Batsford · leaf 646
at an angle of 45 \ Take 3 parts of A to B as a radius, and fromthe point G strike E the upper part of the arch from the point at D to F. Repeat the same processfor the other side of arch. The same centres and radius to scale are used when running mouldingson this form of arch. The moulding may… … ?ig. I. Fig. 2. Fig. 3. No. 205.—Setting out Arches. Iig. 4- parts composing it. The width between the piers or abutments is called the span of the arch,and is measured in a horizontal line, called the springing line, as A B. What is called the rise ofthe arch is the vertical distance measured from…
Plastering · Decoration and ornament, Architectural
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
