The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 128
of the link arcradius. Having thus determined the true radius for the link arca new template should be constructed, and all the locationsmade which are appropriate to the template positions Nos.1, 2, 3, 4, 5, 6, 7, 8, 9, 10, under the new conditions, just asthough no previous investigation had… … MODIFICATIONS. 101 gears but precisely equal iu the mid gear, with a forwardstroke lead opening increasing from I d (Fig. Z) in the fullto Id* in the mid gear, and with a return stroke lead, open-ing gradually from Z2 cP in the full to Z2 db in the mid gear.Both these lead openings will be exactly…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
