The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 56
Fig. 11. t NEUTRAL POSITION. !®T TO THE READER — By sliding the valve pieceback and forth over its ports, avery clear idea will be obtainedof the relative positions of theedges during motion. … Fig. 11. NEUTRAL POSITION. 1±_— To the Reader.— By sliding the valve pieceback and forth over its ports, avery clear idea will be obtainedof the relative positions of theedges during motion. WIDTH OF BKIDGE. 47 WIDTH OF BRIDGE. This dimension is usually made of equal thickness withthe cylinder, in…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
