same in both cases. The current inthe shunt-field winding will remain constant in direction and,as a result, the direction of the magnetic field of the machinedoes not change. The direction of current in the armature,however, changes and as a result the direction of the magneticfield produced by it… … the field current and it is acting downward, as shown in Fig.159, instead of upward, as shown in Fig. 143. Since the mag-netizing effects of the armature current and the field currentare present at the sametime, they form a resultantfield whose general direc-tion is similar to thatshown in Fig.…
