Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 222
is shown in Fig. 175. A small handleto the right of the main controllerhandle, as shown in the figure, ena-bles the motorman to reverse the di-rection of rotation of the motors bychanging the connections. The com-plete wiring diagram of a street caris shown in Fig. 176. When auxiliary devices are… … Fig. 173 of them controlled from any car. The equipment of each carconsists of a series-parallel controller, whose electrical opera-tion is similar to that just described, and so arranged that it iscontrolled from master controllers that are located in themotormans cabs at the ends of the cars. The…
