Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 259
ates to the other. The plates areproperly distanced on these rods by nickel-plated steel spac-ing washers, and ^re held firmly in place and contact bynuts screwed on both ends. In assembling the plates aspecially shaped lug is placed in the center of each of theconnecting rods, as shown in Fig.… … Fig. 206 J STOEAGE BATTERIES 249 in the Edison cell than there are positive, just as there is inthe lead cell, which results in both outside plates being nega-tive. Special insulators are used in separating the plates andpreventing them from coming into contact with the containingcan. 277.…
Electrical engineering
