Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 285
ls. The variation incurrent that may be produced by such a rheostat will dependupon the relation between the resistance of the circuit inwhich the rheostat is connected and its own total resistance.Such rheostats, as a rule, have rather a small current-tarrying capacity. A rheostat composed of a… … Fig. 233 DISTRIBUTION AND OPERATION 275 a small handle shown in the figure. The resistance of thisrheostat is, as a rule, rather low, but its current-carryingcapacity is quite large. Itoperates very satisfactorilyin low voltage circuits andthe variations in its resist-ance can be made verygradual.…
Electrical engineering
