Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 56
drop in potential across the resistance can be deter-mined by means of the voltmeter (V), which should beconnected to the terminals of the resistance, as shown in thefigure. The value of the resistance can be determined by I SEEIES AND DIVIDED CIKCUITS 45 substituting the ammeter and voltmeter… … Fig. 12 ate results when proper care is exercised in reading the in-struments. The method is best suited for the measurement oflow resistances capable of carrying rather large currents, [orthe following reason: The current in the resistance to be meas-ured is not equal to that indicated on the…
Electrical engineering
