Fig. 91 be so located as to give the greatest service. Fig. 90shows an isometric representation of a framing detail,and, although not in accordance with the orthographicworking drawing, shows to an untrained imagination MECHANICAL DRAWING 89 a better idea of the construction. Note the…
