dimensions should exactlyagree with the over-alF measure-ment given. In drawing pencil lines theyshould always be drawn longerthan the actual length of theline to be inked in, so thatthe exact point of intersec-tion with other lines can bebetter seen. When the drawinghas been inked in these… … 142 FRAGTIGAL DRAUGHTSMENS WORK, ing. These construction lines, as they are called, shouldbe drawn as lightly as possible, so as to be easily removed with-out greatly damaging the surface of the paper. When drawingcircles or arcs of circles with the compasses, a little pencil markshould be made…
