Practical draughtsmen's work, with numerous engravings and diagrams (1903)
Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 24
e rather expensive.Framed set-squares (see Fig. 15) are made of three pieces ofmahogany or other wood, edged with ebony. They are built upof three separate parallel pieces of hard wood, joined at thecorners. By means of the open centre, a better hold of the setsquare can be obtained, and it can…
Mechanical drawing
