Fig. 136.—Gardeners Method of Constructing an Ellipse. semicircular arches. In the ordinary way, an arch crosses atright angles to the opening it spans, but in the case of a railway … Fig. 137.—Plan of Skev/ Arch. crossing a road diagonally, or a road crossing a canal similarly, askew bridge is necessitated. In the accompanying plan (Fig. 137),a bridge is shown crossing a roadway with an angle of skew at 80 PRACTICAL DRAUGHTSMENS WORK. ab d o{ ZO degrees. The plan does not show…
